NetAlly Link Live Private Edition

AirMagnet Survey PRO enables network professionals to design, deploy and validate WiFi 6 wireless LAN networks for optimal performance, security and compliance. It also calculates the ideal quantity, placement and configuration of access points for a successful wireless LAN deployment. AirMagnet Survey PRO goes beyond simply verifying RF coverage by plotting actual end-user network performance in terms of connection speed, throughput and packet statistics by allowing you to use any WiFi adapter or AirMapper Site Survey on the AirCheck G2 and EtherScope nXG. AirMagnet Survey PRO helps you get WiFi installations right the first time, preventing costly rework and user complaints. Plan and design WiFi networks without physically rolling out any access points Collect real world data by performing true end-user experience measurements using any WiFi adapter or AirMapper Site Survey on the AirCheck G2 and EtherScope nXG Generate heatmaps that provide full visibility of WiFi coverage, noise SNR, interference, throughput, data rates, retries, loss, Voice-Over-WiFi MOS and more Save time by performing active, passive and spectrum survey in a single walk-through Key Features WiFi 6 Site Survey AirMagnet Surve PRO is a wireless network deployment solution that enables users to measure and assess the true end-user experience of a wireless network using any 802.11 adapter or AirMapper Site Survey on the AirCheck G2 and EtherScope nXG. AirMagnet Survey PRO goes beyong just verifying RF coverage and plots actual end-suer network performance, in terms of throughput and PHY data rates, while taking MU-MIMO and other environmental situations/network configurations into account. The wireless site survey solution reveals the coverage of specific 802.11 parameters that impact perfromance, such as higher MCS schemes and wider channel and intrusion of interference or legacy devices. Results are displayed as a complete WiFi "weather map" of all critical RF and end-user performance metrics. The accountability of "real world" measurements allow IT staff to design and deploy WiFi accurately from start. Helping businesses save time and money, reducing end-user network complaints and recuding costly redesigns of the network. Integration with AirMagnet Planner AirMagnet Planner is built into AirMagnet Survey PRO, providing a single, seamless application as one of the industry´s most complete approaches to wireless LAN design, deployment and ongoing optimization for WiFi 6 networks. With this integrated solution, AirMagnet Planner can be used to accurately design WLANs by modeling building construction materials/obstructions, 802.11 access points and visualizing coverage across multiple floors, then validating the results with real-world data in AirMagnet Survey PRO. Using active end-user performance metrics, users can further perfect their planning models over time. Users also gain additional planning capabilities with the ability to test network plans against the AirWise engine for design requirements. AirMagnet Planner also integrates with AirMagnet Survey Express. "Realworld" Survey Data Collection and Solution of "What-If" Scenarios With the AirMapper app on the AirCheck G2 or EtherScope nXG users can quickly and easily gather location-based WiFi measurements and create visual heat maps of key performance metrics in AirMagnet Survey PRO. Simple to use, the AirMapper app is ideal for quick site surveys of new deployments, change validation and performance verfification. Complete faster and easier WiFi site surveys with an entirely mobile platform Perform enterprise-grade surveys without the need of a dongle or tethered device Collaborate - easily visualize and share survey data through Link-Live cloud service or AirMagnet Survey PRO AirMagnet Survey´s simultaneous wireless site surveying capability leverages multiple adapters plugged into the same PC to provide users with a solution that emulates real-world client behavior (using active and iPerf surveys). Having an accurate wireless emulator tool reduces site surveying time and efforts, cuts cost by half and requires users to walk the floor only once to collect all required data. With this wireless 802.11 site survey tool, users can create "what-if" scenaros to simulate a variety of changes to the network and preview the impacts. Options include changing access point transmit power, channel, SSID settings and the addition of environmental noise. Users can also simulate moving access points to new locations and preview the effect of adding additional access points. AirMagnet Survey PRO empowers users with the option of creating an automated channel plan for access points that avoids interference and over-allocation. Outdoor Wireless Site Surveys With GPS support and integration with Google Earth, AirMagnet Survey PRO provides fully-automated outdoor wireless site surveys. Users can leverage NMAE-compliant GPS devices to automatically collect outdoor wireless data. Users also can import street maps of any city in the world, and have the option to analyze results within the AirMagnet Survey user interface or exported into Google Earth for a zoomed-in view to any street within the city. RF Spectrum and Voice-over-WLAN Surveys Beforem making any design and deployment decisions, users can account for RF interference from non-WiFi devices. Users who own AirMagnet Spectrum XT can collect both WiFi and spectrum analysis data in a single survey and integrate the data into AirMagnet Survey. With this integration, users can visualize the RF energy at any location and identify/display the presence of non-802.11 devices interfering with the WLAN. AirMagnet Survey addresses the challenges faced by network installers and IT staff when deploying VoWLAN networks. With a built-in voice readiness verification system, AirMagnet Survey allow users to ensure that their network design is aligned with the recommendations of the phone vendor. This system also allow users to perform real-world voice surveys by validating and plotting phone call quality, capacity and other voice specific parameters at every location on a floor map helping to identify and minimize issues. Validate user and Application Requirements The AirWise engine allows users to set wireless network design/application requirements, such as signal coverage, wireless network throughput, PHY data rates, 802.11 specific parameters and more to help identify any problem areas. Once set, users are alerted to the areas on the floor map that meet, or do not meet the requirement, enabling them to take the necessary action to solve the coverage, performance or capacity problems. AirWise includes the option to create profiles based on real-world survey data or wireless network modeling data that can be used to verify WLAN deployment readiness for a variety of applications. This single-click assessment of the WLAN network helps save time, effort and money by avoiding costly re-designs of the WLAN network and minimize IT troubleshooting costs. Users can generate a Pass/Fail report that enables an efficient hand-over of results of the survey to the installer or the end-customer. Professional Custom Reports AirMagnet Survey PRO includes a completely integrated reporting module that instantly creates custom outputs of site survey and simulations. Customized templates provide wireless 802.11 site survey users with flexibility by creating various reports based on project requirements. Users can customize reports further by including/excluding sections, adding in notes and customizing logos, headers and footers amongst many other customizable options. Reports can be saved in multiple formats, such as PDF, XML, HTML, Excel or Word. Visualize Coverage and Performance Differences Over Time WiFi environments are very dynamic and to guarantee the best performance for end-users, it is important to be able to verify changes in coverage and performance in the network. AirMagnet Survey´s Diff View feature allows side-by-side visualization of differences between two separate surveys. The Diff View feature helps display how a site´s wireless environment has changed over time. This view is a great tool for System Integrators to drive repeat business of validating the coverage and performance of the network on an on-going basis. Likewise, users can use this feature to quickly compare AirMagnet Planner results with actual site survey results. This information can the be used to fine-tune the dl losses for the building and environmental conditions within Planner for more accurate planning. Integration with WLAN Infrastructure Vendors AirMagnet Survey allows exporting of real-world survey data to Cisco Prime. This is critical for, not only calibrating Cisco´s built-on planner modeling capabilities but also for specialized applications. For example, location services that mandate a calibration site survey for maximizing location accuracy for WLAN clients, or tags and VoWLAN servics that recommend the use of site surveys to validate real-world data versus the predictive capabilities of the infrastructure. Take advantage of the planning capabilities built inside AirMagnet Survey PRO by creating and exporting planner projects directly into Cisco Prime. This integration eliminates the need to repeat these tasks within Cisco Prime, saving users time and resources needed, in setting up of maps, access point placement locations and other WLAN deployment modeling activities. System Requirements for Laptop/Notebook/PC/Tablet PC: Operating Systems: Microsoft Window 8.1 Pro / Enterprise 64 bit or Windows 10 Pro / Enterprise 64 bit Intel Core 2 Duo 2.00 GHz (Intel COre i5 or higher recommended) 4 GB or higher 800 MB free hard disk space USB port or multiple ports in the PC when using multiple adapters AirMagnet-supported wireless network adapter(s) or AirCheck G2/EtherScope nXG with AirMapper (recommended) Optional: AirMagnet Spectrum XT Adapter and license (required for viewing spectrum data and heat map; Survey PRO only) A site map in a format supported by AirMagnet Survey (supported formats are: .bmp, .dib, .dwg, .dxf, .emf, .gif, vsd, .jpg, .wmf, .vdx or .png Google Earth must be installed in order to export the GPS data for outdoor surveys to Google Earth (Survey PRO only) Supported GPS device. Here is a list of GPS devices that have been approved for use with the AirMaget Survey product: Gamin eTrex LEGEND HCx Garmin eTrex Garmin eTrex Legend Garmin GPS18X USB Garmin GPS 18 Deluxe Microsoft GPS-500 SIRF III DeLorme Earthmate GPS LT-20 Magellan eXplorist 500 Pharos iGPS-180 US GlobalSat Buz-353-S4 (recommended) System Requirements for Apple Macbook PRO: Operating Systems: MAC OS X v10.5 (Leopard) or higher running a supported Windows OS (as noted under Laptop/Notebook/PC/Tablet PC section) using Boot Camp Intel based CPU 1.6 GHz or higher 4 GB or higher 800 MB free hard disk space USB Port or multiple ports when using multiple adapters AirMagnet-supported wireless network adapter(s) or AircheckG2/EtherScope nXG with AirMapper (recommended) Optional, AirMagnet Spectrum XT Adapter and license (required for viewing spectrum data and heat map; Survey PRO only) A site map in a format supported by AirMagnet Survey (supported formats are: .bmp, .dib, .dwg, .dxf, .emf, .gif, vsd, .jpg, .wmf, .vdx or .png) Google Earth must be installed in order to export the GPS data for outdoor surveys to Google Earth (Survey PRO only) Supported GPS device. Here is a list of GPS devices that have been approved for use with the AirMagnet Survey product: Garmin eTrex LEGEND HCx Garmin eTrex Garmin eTrex Legend Garmin GPS 18 Deluxe Garmin GPS18X USB Microsoft GPS-500 SIRF III Garmin GPSMap 60 DeLorme Earthmate GPS LT-2 DeLorme Earthmate GPS LT-40 Magellan eXplorist 500 Pharos iGPS-180 US GlobalSat BU-353-S4 (recommended) Supported Adapters: AirMagnet Survey supports two categories of wireless adapters: Preferred Adapters: These adapters have been comprehensively tested by AirMagnet and are recommended for use with AirMagnet Survey PRO. Drivers have been customized for extended feature support. Visit netally.com/products/airmagnet-survey-pro Other Adapters: These adapters can be used with AirMagnet Survey PRO but have not been tested by AirMagnet. Drivers have not been customized, will provide limited features and could provide inaccurate data Note: NetAlly is not responsible for the quality of the test results collected using WiFi adapters not included on the Preferred category. Authentications supported by various adapters vould be limited by their own capabilities, Windows wireless zero configurations and various other reasons.Available downloads: AirMagnet Survey PRO Data Sheet Site Survey Best Practices - White Paper 802.11 USB Adapter FL 20 V2 AirMagnet Survey PRO Preferred Adapters AirMagnet Survey PRO Comparison Table

Rugged instrument for comprehensive network validation and troubleshootingNative WiFi 6, 2,4/5/6 GHz band and Bluetooth / BLE supportQuickly test, verify, troubleshoot and map WiFi networksFaster and easier WiFi and Bluetooth / BLE site surveys with AirMapper Site Survey appQuickly find the physical location of WiFi access points and clients on the 2,4 GHz, 5 GHz and 6 GHz bandsOverviewThe AirCheck G3 Wireless Analyzer´s intuitive user interface provides actionable intelligence, speeding and simplifying wireless deployment, troubleshooting and validation. AirCheck G3 is the most cost effective hardware enabled site survey solution for WiFi 6/6E networks. It provides network professionals of any skill level with complete and accurate information to survey and validate WiFi deployments and changes, resolve connectivity and performance problems quickly, speed up closure of trouble tickets, and ensure your WiFi network meets end users´needs. With powerful tools suited for wireless engineers, but ease of use for technicans and remote "smart hands" AirCheck G3 Pro makes your entire team more productive.Key featuresTest, verify and troubleshoot technology upgrades, WiFi 6/6E networks and Bluetooth / BLE devices with advanced testing apps and purpose built hardwareValidate WiFi 6/6E network performance for critical services and key end devicesSupports full 2,4 GHz and 5 GHz spectrum analysis with the optional NXT-1000 portable spectrum analyzer adapterEnables remote engineers to troubleshoot and collaborate with on-site technicans with cloud remote control in Link LiveSeamlessly consolidate and manage field test data and integrate with network management systems via Link LiveFlexible Platform Addresses Multiple TechnologiesNative 2x2 WiFi 6/6E radio that supports:- 802.11 a/b/g/n/ac/ax WiFi network connectivity- Analysis of SSIDs, BSSIDs, channel, client devices and interference soures1x1 WiFi 5 radio that supports:- remote control connection and testing- Network discovery and topology mappingBulit-in Bluetooth v5 / BLE radio for peripheral connectivity and conducting Bluetooth / BLE site surveysUSB interfaces provide connectivity for accessories and other devicesNative WiFi 6 and 6 GHz supportWith the introduction of WiFi 6/6E how WiFi validation and troubleshooting is done has changed. New technologies designed to improve traffic management efficiency and support for the 6 GHZ band were introduced, allowing for higher throughput and better performance in environments where a high user capacity is required - necessitating new technology to test and validate these networks.Validate actual WiFi 6/6E network performance by using native 802.11ax radio Gain visibility into all WiFi devices working on the 2,4 GHz, 5 GHz and 6 GHZ bands*Enables packet captures of WiFi 6 control, management and data frames in all three bandsDiagnose new WiFi 6E mechanismus of Reduced Neighbor Reports, Preferred Scanning channels and multi BSSIDsAuthenticate using the latest security standard of WPA3 and Enhanced Open*NOTE: WiFi 6/6E regulatory compliance implementation of the 6 GHz spectrum varies by country. AirCheck G3 models are available in three versions; see Models and Accessories for additional information.AirMapper Site Survey - Now supporting WiFi 6/6EWith the AirMapper app, AirCheck G3 users can quickly and easily gather location based WiFi and Bluetooth / BLE measurements and create visual heat maps of key performance metrics in the Link Live collaboration, reporting and analysis platform. Simple to use, the AirMapper app is ideal for quick site surveys of new deployments, change validation and performance verification.Faster and easier WiFi and Bluetooth / BLE site surveys with a rugged handheld analyzerAutomatically identify common WiFi network problems using InSites intelligence analysis in Link LiveCollaborate - easily visualize and share survey data through Link LiveSimultaneous passive and active WiFi surveys to gather critical site metrics and validate client experience and roaming with one surveyExport WiFi survey data to AirMagnet Survey Pro for more advanced analysis, planning and reportingSurvey project management capabilities in Link Live provide a major boost in productivity and collaboration for distributed teams conducting surveys at remote sites. A team lead can create a project in Link Live, upload and calibrate the floor plan, then automatically push the configured project out to the desired remote analyzers.Spectrum Analysis and InterferenceTrying to pinpoint the source of WiFi interference on a wireless network is hit or miss with the wrong tools. Through the use of the optional NXT-1000 Mobile Spectrum Analyzer, AirCheck G3 offers a view of RF interference in the 2,4 GHz and 5 GHz bands and its impact on the wireless network´s overall performance. Key graphs and charts include:Real-Time Spectrum: provides a live RF view including current, average and max readingsFrequency Spectrum: Display heat mapped signal density to identify recurring energySpectogram: Shows energy over time to identify the periodic nature of the RF environmentVerify complex wireless networksTest automation speeds and simplifies validation and troubleshooting - so more people can solve more problems, faster.Out-of-the-box AutoTest profiles for WiFi networks that can be customized for your deploymentExecute multiple AutoTest profiles that shorten test time to verify multiple WiFi SSIDsDefine and assign groups of targets to AutoTest profiles to verify performance using Ping, TCP Connect, Web or FTPWired + WiFi network discovery, mapping, analysis and security auditsInstantly see what is on the network and where it is connected. Quickly investigate and locate "suspect" devices and identify problems associated with device misconfigurations.Discovers network devices across multiple VLANs and WiFi SSIDsDiscovery difference analysis in Link Live exposes possible security risks in the network infrastructure by showing changes in connected devicesPowerful filter and sort function with automatic problem detection identifies issues such as:- Duplicate IPs, congested switch ports and oversubscribed WiFi channels / SSIDs- Security issues, such as unknown switches, access points with open authenticationPath analysis shows the switch/router path to any connected deviceBatch authorization workflow makes it easy to identify known vs. unknown devices, enabling "who´s on my network" auditing.WiFi performance test and packet captureVerify WiFi performance and easily capture packets for detailed application analysis.Simultaneously generate and measure IP based traffic through the use of two WiFi radiosSupports popular iPerf network throughput testing for WiFi networksCapture wireless traffic to PCAP files for escalation evidence or analysis, with simple but powerful - filtering  and slicing controls.Simplified collaboration, automated reportingCollaborate with staff across your organization with centralized visibility of distributed tests, speeding resolution of remote site issues.Link Live collaboration, reporting and analysis platform (cloud based or private / on premise) stores test result and site data upload for automated reporting and documentationSimplifies report generation for network deployment documentationAttach screenshots and user comments to each result, adding context for future changes and troubleshootingAvailable API enables seamless data integration between Link Live and trouble ticket or network management systemsModels & AccessoriesImportant notes: WiFi 6/6E regulatory compliance implementation of the 6 GHz spectrum varies by country.AirCheck G3 models are available in three versions: Full Tri-Band (capability across the entire 6 GHz band), Partial Tri-Band (capability for only certain channels in the 6 GHz band as determined by 802.11d regulatory domain information), and Dual Band only (for countries where operation in the 6 GHz band is not allowed). Be sure to select the model that is certified for use in your specific country. Please contact us for more information.The models shown on the table below are for the "Full Tri-Band" version. Replace "AIRCHECK-G3-PRo" with the following for the other model types:AIRCHECK-G3E-PRO     Partial Tri-BandAIRCHECK-G3C-PRO     Dual Band Only (2,4 / 5 GHz)Inclusion of AllyCare SupportAll new AIRCHECK-G3-PRo mainframes are sold with the first year (1 year) of AllyCare support included. Additional year(s) of support may be added. Product registration and activation is required within 30 days of first power on. Model Number / Name Description AIRCHECK-G3-PRO Includes: AIRCHECK-G3-PRO mainframe with 1 year of AllyCare support (AIRCHECK-G3-PRO-1YS, shoulder sling bag, AC charger, Quick Start Guide. AIRCHECK-G3-PRO-KT Includes: AIRCHECK-G3-PRO mainframe with 1 year of AllyCare support (AIRCHECK-G3-PRO-1YS), shoulder sling bag, AC charger, Quick Start Guide, external directional antenna, holster and NXT-1000 spectrum analyzer. AIRCHECK-G3-PRO-TKT Includes: AIRCHECK-G3-PRO mainframe with 1 year of AllyCare support (AIRCHECK-G3-PRO-1YS), shoulder sling bag, AC charger, Quick Start Guide, external directional antenna, holster, NXT-1000 spectrum analyzer and Test Accessory. EXT-ANT-TRIBAND 2,4 / 5 / 6 GHz directional antenna for use with AirCheck G3 and EtherScope nXG NXT-1000 NXT-1000 portable spectrum analyzer G3-PWRADAPTER AC charger replacement / spare for AIRCHECK-G3-PRO mainframe with country power cords G3-REPL-BA Lithium ION replacement battery for use with the AirCheck G3 Holster-G3 Field use carrying holster makes troubleshooting on the go easier. Openings allow access to all applicable buttons and interfaces. AllyCare Support - One year of support is included. Use these support model numbers for extending support at time of purchase or for support renewal. AIRCHECK-G3-PRO-1YS 1 year AllyCare support for all AIRCHECK G3 Pro models, including "E" (Partial Tri-Band) and "C" (Dual Band only) SKU´S: AIRCHECK-G3-PRO, AIRCHECK-G3-PRO-KT, AIRCHECK-G3-PRO-TKT AIRCHECK-G3-PRO-3YS 3 years of AllyCare support for all AIRCHECK G3 PRO models, including "E" (Partial Tri-Band) and "C" (Dual Band only) SKU´S: AIRCHECK-G3-PRO, AIRCHECK-G3-PRO-KT, AIRCHECK-G3-PRO-TKT General Dimensions in mm 102 mm x 196 mm x 42 mm Weight 0,48 kg Battery Rechargeable lithium-ion battery pack (3.63 V, 9,75 A, 35,39 Wh) Battery Life Typical operating life is 10 hours (Battery life from full charge varies depending on the feature being used); Typical charge time is 3 - 4 hours Display 5.0 inch colour LCD with capacitive touchscreen (720 x 1280 pixels) Host interface 2 USB Type-A PortsUSB Type-C Power and On-the-Go PortRP-SMA External Antenna Port Charging USB Type-C 45-W adapter: AC input Power 100-240 V, 50-60 Hz; DC Output Power 15V (3A) Wireless AirCheck G3 has two internal WiFi radios: Testing: 2x2 Tri-band 802.11ax wireless radion (IEEE 802.11 a/b/g/n/ac/ax compliant)Management: 1x1 Dual-band 802.11ac Wave2 + Bluetooth 5.0 and BLE wireless radio (IEEE 802.11 a/b/g/n/ac compliant Specification Compliance IEEE 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax WiFi Connectivity 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax Operating frequencies NOTE: These are the center frequencies of the channels that the AirCheck G3 tester supports. Frequencies of channels received and transmitted:2,4 GHz band: 2.412 to 2.484 GHz (channel 1 to channel 14)*5 GHz band: 5.170 to 5.320 GHz, 5.500 to 5.700 GHz, 5.745 to 5.825 GHz (channel 36 to channel 165)*6 GHz: 5.925 to 7.125 GHz (channel 1 to channel 233)*(*) Where allowed by country regulations.NOTE: The tester transmits only on the frequencies allowed in the country where it is operating. Antennas Internal WiFi Antennas Minimum gain 2.0 dBi peak in the 2.4 GHz band, 1.5 dBi peak in the 5 GHz band and 2.7 dBi peak in the 6 GHz band. External Directional Antenna Antenna frequency range 2,4 GHz to 2,5 GHz, 4,9 GHz to 5,9 GHz and 6.0 to 7,1 GhZ.Minimum gain 6,4 dBi peak in the 2,4 GHz band, 8.9 dBi peak in the 5 GHz band and 8.6 dBi peak in the 6 GHz band. download datasheet

Introducing the new LinkRunner 10G Advanced Ethernet Tester, the most cost effective solution for 10 Gig network testing. LinkRunner 10G simplifies testing and configuration of copper and fiber Ethernet networks, streamlining workflows by combining essential functions of installation and triage in a single, ruggedized unit. The next generation Android based tester delivers complete network validation and troubleshooting, from the media (copper/fiber) to the application (Layers 1-7), accelerating deployments, speeding problem identification and improving the efficiency and effectiveness of network installers and operations teams. Install, test, verify and troubleshoot technology upgrades, Multi-Gig (NBASE-T) and10G networks with advanced Android based troubleshooting apps and purpose built test hardware Physical layer testing includes cable (TDR) testing, toning, wiremapping and cable SNR (Signal-to Noise Radio) for Multi Gig links Compatibility with standards compliant SFPs enables test and validation of any wired media (copper or fiber) for a variety of use models Validate up to 90W 802.3bt PSE with TruePower loaded Power over Ethernet (PoE) test Serves as a peer to the EtherScope nXG for line-rate performance testing to verify network capacity, performance and QoS, as well as service provider SLAs between sites Key Features Flexible Platform for a variety of testing needs The LinkRunner 10G has two Ethernet ports. The main test RJ-45 port supports Multi-Gig networks from 10/100/1000 Mbps to 2.5/5/10G to verify link speed, SNR and duplex advertised and connected. It can request and verify PoE power under load from uip to 90W PSE´s. Alternatively, it can interface to fiber networks via single/multi mode SFP+ to test 1/10Gbps fiber based Ethernet. The second RJ-45 management port connects to 10/100/1000 Mbps Ethernet for remote control, and conducts network scanning and tests where needed. It is also the port for cable testing. In addition to fiber optic transceivers (SX, LX, SR, LR, ZX, singlemode, multimode, etc.) the SFP+ slot can be utilized with a variety of standards-based interfaces, such as TwinAx or other Direct Attach Copper (DAC) cables, and vendor specific transceivers. As an Android based device, LinkRunner 10G can use a variety of apps from the Live-Live app store for a variety of uses. The USB-A port provides connectivity for added USB adapters and third party accessories such as printers, barcode scanners, fiber optic inspection cameras and more. The use of a USB based WiFi adapter (such as the Edimax AC1200 for 802.11ac/b/g/n) provides for connectivity and wireless testing using a third party app. The USB-C port is compatible with higher power USB-C chargers, as well as external power packs for all day portable use. Simplifies tasks and empowers technicians to verify complex networks with the next generation AutoTest The LinkRunner 10G has out-of-the-box AutoTest profiles with best practice pass/fail thresholds for quick assessment of network configurations and services. AutoTest Element Configurations include: Switch port PoE validation up to 90W from PSE and TruePower load testing 802.1x autthentication Link speed/duplex advertised vs. actual, Multi-Gig link SNR measurement VLAN tagged traffic detection & monitoring Witch port identification with interface stats, connected devices and drill-down DHCP availability, response time, automatic detection fo 2nd DHCP offer and connect log DNS lookup (forward/reverse) availability and response time Gateway availability and response time Active connection test targets (Ping or TCP Connect) End-user response time measurement via HTTP Multiple profiles can be created for complex networks with multiple VLANs supported per switch port, each with its own set of IP targets. These can then be organized into profile groups that execute each test against each profile in sequence. The result is that multiple VLANs can be verified and documented in one go. Since the pre-defined profiles can be executed individually, the profiles group serves as a resource for technicians to verify each specific VLAN during troubleshooting. With profile groups, engineers can transfer their network configuration and test knowledge to technicians, saving training time and effort. Multi-Gig Link Validation With the expanding deplayment of Multi-Gig switching (typically to feed greater bandwith to WiFi 6 access points), users are finding that their cable plant may not support the desired speed. Cable quality, length, installation workmanship, and noise in the environment all can contribute to "downshifting" to lower-than-expected-speeds. Cabling SNR Measurement - LinkRunner 10G can now verify copper media for Multi-Gig capability (1 / 2.5 / 5 / 10G), and provide root cause diagnosis when link speed downshifting occurs. 24 hour monitoring for intermittent issues Periodic AutoTest: In this mode, AutoTest runs at specified intervals (from 1 minute to 24 hours) and sends the results to Link-Live to view the results over time. This is an effective way to "monitor" aspects of your network for an extended period, or to help diagnose intermittent issues without having to manually execute multiple tests. Results are automatically timestamped and can be prefixed with a user-entered comment for grouping or organization. Test results can be quickly analyzed in Link-Live using the filtering and sorting functions. Email notifications can warn you when errors are found. 10G copper/fiber wired performance tests for critical links and key devices The LinkRunner 10G works as a test peer with the EtherScope nXG Network Performance Test (NPT) to stress critical network links, such as switch ports to servers/storag/WiFi access points, uplinks or WAN links, with up to four simultaneous data streams at up to 10G line rate. It verifies the link´s compliance to service level agreements (SLA) based on throughput, packet loss, QoS, delay and jitter. This performance test can be run at up to full line rate in order to measure the top end bandwith and quality of your network from end-to-end, or for particular network segments. It can also be utilized to bench test switches for optimal configuration prior to rollout into production. For troubleshooting on a production network (where excessive test traffic could be detrimental), many users will configure the NPT feature with a low stream of traffic (even just 128 Kbps) in order to characterize network quality, identify possible packet loss, delay and jitter and validate Qos. Settings for data streams and thresholds for VoIP or video service can be stored and recalled where needed, saving configuration time. For key servers/services in the cloud or internet, engineers can pre-define tests and thresholds to verify their connectivity and performance using ping, TCP connect, HTTP or FTP. Continuous testing with response time measurements is available to verify consistency and identify intermittent issues. These tests can be easily recalled by field technicians to reduce configuration time or mistakes, to get more done faster. List of problems automatically detected by LinkRunner 10G discovery enabled Bad Subnet Mask Duplicate IP Address DHCP server not responding LinkRunner 10G received used IP from DHCP LinkRunner 10 lost DHCP lease max clients on SSID high interface utilization* high interface errors* high FCS errors* high packet discards* detected half-duplex interfaces high CPU unilization* high disk utilization* high memory utilization* recent device reboot* spanning tree topology change SNMPv3 Agent Responded to SNMPv1/v2 Query (* problems detected wither user-definable threshold) Additional troubleshooting tools Packet capture: You can capture up to 10G line rate to create a PCAP file of up to 1 GB. Packet slicing and filtering are supported and PCAp files can be uploaded to the Link-Live cloud service for easy sharing. Cable test: determine length, shorts, and split pairs and locate opens on UTP cable. Verify the wiremap of UTP and ScTP cable with a WireView adapter. It can generate either analog tone or the unique digital tone for the Fluke Networks IntelliTone Probe for quick cable tracing. Android Apps: users can download apps from the Link-Live app store to accomplish many tasks in addition to testing. Automated test results management Serving as a centralized test result and device management system, the free Link-Live cloud service transforms team workflows with the ability to quickly and easily log, document and report test activity from all LinkSprinter, LinkRunner AT, LinkRunner G2, LinkRunner 10G, AirCheck G2 handheld network testers. Once the instrument is connected to the Link-Live cloud service, your test results are automatically uploaded to the dashboard for project management and reporting. You have the option of uploading additional files, screenshots, images, profiles, packet captures, location information and comments anytime. Also, certain NetAlly instruments with AllyCare support can receive firmware updates "over the network" from Link-Live as they become available. An API is available to retrieve and integrate data from Link-Live into other management platforms, such as your trouble ticket application or network management system. This gives you the ability to easily provide proof-of-performance and better manage jobs and staff efficiency. This unified dashboard of both wired and WiFi network connectivity results enables you to: reduce results management overhead for multiple testers and users enables seamless collaboration between site personnel and remote experts Attach photos, user comments to each result, adding context for future changes and troubleshooting for asset management, ability to associate serial numbers of installed devices, and/or cable/walljack label to specific test results WiFi network visibility With the use of a USB-A based WiFi adapter (such as Edimax AC1200 for 802.11ac/b/g/n) provides for connectivity and wireless testing using a third party apps, available for download from the Link-Live app store. While not nearly as powerful as the tools available in EtherScope nXG or AirCheck G2, this capability provides an essential level of visibility where needed. Note, other than the upload/attachment of screen captures, there is no integration from third party apps with Link-Live. Information collected from these apps can not be saved to Link-Live (another reason to utilize EtherScope nXG or AirCheck G2 for WiFi troubleshooting.) AllyCare - Enabled features deliver advanced troubleshooting capabilities(The following features below are only available to customers with AllyCare support on their LinkRunner 10G. Visit support.netally.com/allycare Discovery - Know who and what is on your network The LinkRunner 10G discovery app automatically discovers your network immediatley upon power-up. The discovery provides quick security and health audits of the network devices across multiple VLANs and subnets. Devices are classified and correlated to provide complete visibility of thier name, network addresses, VLAN, SSID, device type, and where available, traffic statistics. Engineers can name and set authorization status for devices discovered. Discovery results can be directly uploaded to the complimentary Link-Live cloud service for storage, conduct detailed analysis of devices discovered with filter and sort tools, or export to CSV/PDF files as documentation. LinkRunner´s discovery can be enriched by accessing SNMP MIBs of infrastructure devices. It shows details such as device configuration summary, interface configuration and traffic detail, SSIDs supported by WiFi controllers, and devices directly connected to switches. Community strings entered are concealed from view. Discover possible security risks caused by users and others: 2nd DHCP offers indicating possible rogue servers, unknown switches granting access to multiple devices. The LinkRunner 10G´s discovery automatically detects problems. It shows possible cause(s) for each problem detected, and it has integrated troubleshooting tools to investigate further to get to root cause. Switch Management Drill into switch interfaces via SNMP for additional diagnostics, including trend graphs on utilization, errors, discards, half-duplex (HDX), RSTP and recent reboots. Path Analysis Shows the switch/router path connecting the LinkRunner 10G to an IP device on across wired and WiFi networks and even beyond the local network, e.g., from the LinkRunner 10G´s test port to a server in the cloud or data center. The LinkRunner 10G offers built-in tools to conduct further analysis of the devices along the path: view configuration, interface traffic statistics, launch Telnet of browser, conduct port scan, ping and more. Simple "Access-Anywhere" Remote Control LinkRunner 10G permits a remote engineer to control the EtherScope nXG "out of band" (using VNC) to collaborate with technicians on-site, or to troubleshoot remotely where there is no local staff. But connecting to distant sites via VNC on different networks is difficult or impossible, particularly behind NAT firewalls. With the AllyCare-enabled web remote control, users can instantly connect to remote units through the Link-Live cloud service - anywhere in the world - for collaborative and remote troubleshooting. Network Topology Mapping - Integrated Wired and WiFi Network Diagrams No more struggling to keep manually drwan maps up to date! LinkRunner 10G (with AllyCare support) automatically discovers both your wired and WiFi networks for instant mapping in NetAlly´s Link-Live cloud service. These comprehensive, up-to-the-minute-accurate network diagrams show your network as it is NOW, integrating Layer 2 and Layer 3 topology information, including these connections: switch to host, switch to Access Point, Access Point to WiFi client, switch to switch, switch to router and router to router hops. Now, users can now interact with the network in a flexible map-based user interface to quickly visually identify configuration and topology issues, speeding troubleshooting and automatically create network documentation. The LinkRunner 10G´s patented discovery engine gathers data from its wired connection (via SNMP and other methods) and from the air (observing WiFi traffic) to generate comprehensive network connectivity maps. Easy to use filters and map controls allow you to see exactly what you want and how you want it displayed. Quickly identify network and device configuration errors and see "unknown" switches and rogue devices. Element icons are color-coded to identify errors or warnings; double-clicking on any map element brings up its detailed discovery information, including status, problems, interface information and more. The importance of visualizing your network The faster engineers can "see" what is going on in their network, to know who is on the network and where they are connected, and what the path is from "here to there", the faster they can get to root cause when troubleshooting performance issues. This is especially true for maintenance organizations or system integrators who often troubleshoot an "unknown" network. The problem is that traditional methods (CLI or element managers) take too long and present complex data that´s often hard to interpret and difficult to correlate. Documentation is an essential step for any project, such as pre-deployment network assessments and new technology rollouts, but it can take too much time to complete. From the graphical map based user interface, one click sends the map data through a Visio file generator, pre-populating the diagram with all discovered devices, links, and corresponding configuration information, saving hours of manual effort, allowing further customization. Ideal for enterprises or service organizations, LinkRunner 10G´s mapping function saves hours of manual labor, allowing documentation to keep up as the network changes, or provide instant maps for client projects. Specifications: Dimensions: 4.05 in x 7.67 in x 2.16 in (10.3 cm x 19.5 cm x 5.5 cm) Weight: 1.68 oz (0.77 kg) Battery: Rechargeable lithium-ion battery pack (7.2V, 6.4 A, 46 Wh) Display: 5.0 in color LCD with capacitive touch screen (720 x 1280 pixels) Host inferfaces: RJ-45 and SFP Analysis ports, RJ-45 cable test port and management port, USB Type-A port and USB Type-C On-the-Go port SD card slot: supports micro SD storage - up to 64GB supported Memory: Approx. 8 GB available for storing test results and user applications, 1 GB packet capture buffer Charging: USB Type-C 45W adapter: 100-240 Vac, 50-60 Hz; DC output power 15 V (3 A) Media Access: Copper: 10M/100M/1G/2.5G/5G/10G - Fiber SFP Adapters: 1G/10GBASE-X Supported IEEE Standards: Wired: 802.3/ab/ae/an/bz/i/u/z - PoE: 802.3af/at/bt/, Class 0-8 and UPOE Cable Test: Pair lenghts, opens, shorts, split pairs, crossed, straight through and WireView ID Multi-Gig link Signal-to-Noise (SNR) measurement (5 db threshold) Operating temperature: 32°F to 113°F (0°C to +45°C) Operating relative humidity (% RH without condensation): 90% (50°F to 95°F; 10°C to 35°C) - 75% (95°F to 113°F; 35°C to 35°C) Storage temperature: -4°F to 140°F (-20°C to +60°C) Shock and vibration: Meets the requirements of MIL-PRF-28800F for Class 3 Equipment Safety: IEC 61010-1:2010: Pollution degree 2 Altitude Operating: 4.000 m; Storage: 12.000 m EMC: IEC 61326-1: Basic Electromagnetic Environment; CISPR 11: Group 1, Class A conforms to relevant European Union directives conforms to relevant Australian Safety and EMC standards complies with 47 CFR Part 15 requirements of the U.S. Federal Communications Commission listed by the Canadian Standards AssociationAvailable downloads: Data Sheet NetAlly-LRG-DS-20-V4 Quick Start Guide (ENG) User Guide v1.4 Capability Comparison (2021)
